MLE Series
The MLE Series is designed for ESD and overvoltage protection in consumer and medical electronics. Below is a detailed introduction.
Series Features
Customizable
In addition to standard models, the MLE Series can be customized to meet ESD protection needs in consumer/medical electronics.
Product Features
Size: 0201in ~ 0603in
Operating Voltage: 5V ~ 80V
ESD Protection Level: 8KV ~ 15KV
Capacitance: 0.8pF ~ 100pF
Operating Temperature: -55°C ~ 125°C
Compliant with IEC61000-4-2
Series Advantages
Easy layout, anti-static, capacitive matching
Easy layout
Compatible with resistors and capacitors of the same size, making PCB layout easier.
Anti-static
Multilayer structure enhances ESD resistance.
Capacitive matching
Multiple capacitance values available to suit circuit design needs.
Product Specifications
| Part Number | Working Voltage | Breakdown Voltage | Clamping Voltage | Capacitance | ESD Contact | ESD Air |
|---|---|---|---|---|---|---|
| 0201-050E050PP-LF | 5V | 28V~38V | 72V | 5.0pF(+80~-20%) | 8KV | 15KV |
| 0201-050E100NP-LF | 5V | 28V~38V | 72V | 10pF(±30%) | 8KV | 15KV |
| 0201-050E330NP-LF | 5V | 18V~28V | 48V | 33pF(±30%) | 8KV | 15KV |
| 0201-120E0R8PP-LF | 12V | 100V~150V | 200V | 0.8pF(+80~-20%) | 8KV | 15KV |
| 0201-120E2R5PP-LF | 12V | 60V~80V | 130V | 2.5pF(+80~-20%) | 8KV | 15KV |
| 0402-050E050PP-LF | 5V | 28V~38V | 72V | 5.0pF(+80~-20%) | 8KV | 15KV |
| 0402-050E100NP-LF | 5V | 28V~38V | 72V | 10pF(±30%) | 8KV | 15KV |
| 0402-050E220NP-LF | 5V | 18V~28V | 52V | 22pF(±30%) | 8KV | 15KV |
| 0402-050E330NP-LF | 5V | 18V~28V | 52V | 33pF(±30%) | 8KV | 15KV |
| 0402-050E560NP-LF | 5V | 18V~28V | 52V | 56pF(±30%) | 8KV | 15KV |
| 0402-050E101NP-LF | 5V | 18V~28V | 52V | 100pF(±30%) | 8KV | 15KV |
| 0402-120E050PP-LF | 12V | 28V~38V | 72V | 5.0pF(+80~-20%) | 8KV | 15KV |
| 0402-120E100NP-LF | 12V | 28V~38V | 72V | 10pF(±30%) | 8KV | 15KV |
| 0402-120E220NP-LF | 12V | 20V~30V | 55V | 22pF(±30%) | 8KV | 15KV |
| 0402-120E330NP-LF | 12V | 20V~30V | 55V | 33pF(±30%) | 8KV | 15KV |
| 0402-120E560NP-LF | 12V | 20V~30V | 55V | 56pF(±30%) | 8KV | 15KV |
| 0402-120E101NP-LF | 12V | 20V~30V | 55V | 100pF(±30%) | 8KV | 15KV |
| 0402-180E0R8PP-LF | 18V | 100V~150V | 200V | 0.6~1.5pF(+80~-20%) | 8KV | 15KV |
| 0402-180E100NP-LF | 18V | 35V~45V | 85V | 10pF(±30%) | 8KV | 15KV |
| 0402-240E0R8PP-LF | 24V | 100V~150V | 200V | 0.8pF(+80~-20%) | 8KV | 15KV |
| 0402-240E1R8PP-LF | 24V | 100V~150V | 200V | 1.8pF(+80~-20%) | 8KV | 15KV |
| 0402-240E2R5PP-LF | 24V | 100V~150V | 200V | 2.5pF(+80~-20%) | 8KV | 15KV |
| 0402-240E3R0PP-LF | 24V | 48V~72V | 110V | 3.0pF(+80~-20%) | 8KV | 15KV |
| 0402-420E0R8PP-LF | 42V | 100V~150V | 200V | 0.8pF(+80~-20%) | 8KV | 15KV |
| 0402-420E2R5PP-LF | 42V | 100V~150V | 200V | 2.5pF(+80~-20%) | 8KV | 15KV |
| 0603-050E050PP-LF | 5V | 20V~30V | 55V | 5.0pF(+80~-20%) | 8KV | 15KV |
| 0603-050E100NP-LF | 5V | 24V~36V | 65V | 10pF(±30%) | 8KV | 15KV |
| 0603-050E220NP-LF | 5V | 15V~25V | 34V | 22pF(±30%) | 8KV | 15KV |
| 0603-050E330NP-LF | 5V | 15V~25V | 34V | 33pF(±30%) | 8KV | 15KV |
| 0603-050E560NP-LF | 5V | 15V~25V | 36V | 56pF(±30%) | 8KV | 15KV |
| 0603-050E101NP-LF | 5V | 15V~25V | 36V | 100pF(±30%) | 8KV | 15KV |
| 0603-5R5T100NP-LF | 5V | 15V~20V | 36V | 10pF(±30%) | 8KV | 15KV |
| 0603-120E050PP-LF | 12V | 33V~50V | 85V | 5.0pF(+80~-20%) | 8KV | 15KV |
| 0603-120E100NP-LF | 12V | 27V~42V | 60V | 10pF(±30%) | 8KV | 15KV |
| 0603-120E220NP-LF | 12V | 20V~30V | 55V | 22pF(±30%) | 8KV | 15KV |
| 0603-120E330NP-LF | 12V | 20V~30V | 55V | 33pF(±30%) | 8KV | 15KV |
| 0603-120E101NP-LF | 12V | 20V~30V | 55V | 100pF(±30%) | 8KV | 15KV |
| 0603-240E0R8PP-LF | 24V | 100V~150V | 200V | 0.8pF(+80~-20%) | 8KV | 15KV |
| 0603-240E2R5PP-LF | 24V | 100V~150V | 200V | 2.5pF(+80~-20%) | 8KV | 15KV |
| 0603-240E3R0PP-LF | 24V | 48V~72V | 110V | 3.0pF(+80~-20%) | 8KV | 15KV |
| 0603-850E2R5PP-LF | 85V | 140V~180V | 240V | 2~4.5pF(+80~-20%) | 8KV | 15KV |
| 0805-050E560NP-LF | 5V | 20V~28V | 60V | 56pF(±30%) | 8KV | 15KV |
| 0805-120E560NP-LF | 12V | 20V~30V | 60V | 56pF(±30%) | 8KV | 15KV |
| 0805-120E101NP-LF | 12V | 20V~28V | 60V | 100pF(±30%) | 8KV | 15KV |
Application Scenarios
Various Data and AV Interfaces
USB (2.0, 3.0, Type-C): Prevents ESD damage to chips.
HDMI, DisplayPort, VGA: Protect video transmission ports and maintain signal integrity.
HDMI, DisplayPort, VGA: Protect video transmission ports and maintain signal integrity.
Consumer Electronics
Smartphones, tablets, and laptops: ESD protection for charging ports, touchscreens, and connectors.
Wearable devices (smartwatches, VR/AR): Protect data ports and sensors from static interference.
TVs and Set-Top Boxes: Protect HDMI, USB, and similar ports from transient voltages.
Wearable devices (smartwatches, VR/AR): Protect data ports and sensors from static interference.
TVs and Set-Top Boxes: Protect HDMI, USB, and similar ports from transient voltages.
Industrial & Medical Equipment
Protect I/O interfaces of PLCs in industrial automation.
ESD protection for medical devices like ultrasound and monitors ensures data accuracy and stable operation.
ESD protection for medical devices like ultrasound and monitors ensures data accuracy and stable operation.
Power & Charging Equipment
Prevent high-voltage surges in USB-C PD charging applications.
Protect DC-DC converters and power management systems in solar inverters.
Ensure communication interface stability in EV charging stations by guarding against high-voltage surges.
Protect DC-DC converters and power management systems in solar inverters.
Ensure communication interface stability in EV charging stations by guarding against high-voltage surges.
The MLE Series is widely applied in ESD protection, especially in areas such as data transmission, automotive electronics, consumer electronics, industrial, and medical equipment. Selecting the right MLE Series requires considering voltage, power, response time, and packaging to ensure system stability and reliability.
