Technology Advantages

Technology Advantages

In order to reduce energy consumption, create a green workplace and protect the global environment, the company continues to promote the following important environmental protection and energy conservation work in order to fully respond to government policies and world trends: ”Energy saving and carbon reduction, protecting the earth” policy, which mainly promotes content and results analysis as following:

(1) Reduce debinding and sintering temperature and time, greatly reduce electricity consumption and reduce carbon dioxide emissions:

Through formula adjustment, powder nanonization and modification, debinding and sintering process and other comprehensive improvements, debinding and sintering can be performed at the same time to reduce debinding time; due to the research and modification of the formula, lower sintering can be used simultaneously Temperature, so it can greatly reduce electricity consumption and achieve the purpose of energy saving and carbon reduction.

(2) Use pure silver inner electrode:

Through formula adjustment, powder nanonization and modification, debinding and sintering process and other comprehensive improvements, it is possible to use platinum and palladium and other precious metal internal electrodes instead of pure silver internal electrodes, greatly reducing rare and precious metals usage.

(3) Reduce the leakage current of the product and reduce the customer's electricity bill:

Through formula adjustment, powder nanometerization and modification, the added ceramic oxide can fully cover the zinc oxide grains, making the conductivity of zinc oxide better, and simultaneously greatly reducing the leakage current, which can be greatly improved reduce the power consumption of products to achieve the purpose of energy saving and carbon reduction.

(4) Reduce the use of organic solvents:

Through the unique powder-making technology and the adjustment of the polarity of the ceramic raw material powder, the selection range of organic solvents can be broadened, and benzene and other solvents harmful to human health can be completely eliminated, and the amount of organic solvents is also greatly reduced at the same time.

(5) High current/high potential gradient and high temperature withstand ability SMD product development:

Through formula adjustment, powder nanonization and modification, debinding and sintering process and other comprehensive improvements, the company can produce SMD products that meet high flux/high potential gradient and high temperature resistance (the highest level in the world), which can meet various needs. Strict application requirements (such as vehicle/base station/surge arrester, etc.) allow customers to reduce the use of plug-in products and avoid waste of electricity and resources required for secondary waste.
Technology Advantages Features

Technology Advantages Features

Innovation Technology

1. Use doping technology to increase the charge conduction ability to improve its semiconducting degree.
2. Prepare a variety of functional sintered materials by using nanotechnology to complete low-temperature sintering characteristics.
3. Use the second-doping and add positive temperature coefficient materials to increase the ability of the product to be used in high-temperature environments.
4. Use pure silver (Ag) inner electrode, excellent conductivity, improve surge capacity.

Innovation Production

1.The preparation of zinc oxide powder is completed by two independent processes (traditionally, one is used), so that it can be semiconducting, and the characteristics can be controlled and adjusted to make the functional design easy to achieve.

Energy saving and environmental protection

1. Significantly reduce the sintering temperature and time of the product to meet government's of energy conservation and carbon reduction policy.
2. Change the surface polarity of ZnO powder, easy to mix with solvent and reduce ball milling time (energy saving).
3. To meet environmental protection needs, non-toxic ester solvents are used, and the use of toxic benzene solvents is greatly reduced (environmental protection).

Marketing value

1. Market products will be mainly thin and small.
2. Product size diversification (neatization), can be independently developed and customized capabilities.
